Mechanical Oil Control Gun

Price on Request

13 products sold in last 11 hours

Selling fast! Over 13 people have in their cart

Super accuracy heavy duty gun for controlling fluid deliveries in most demanding applications.

24 people are viewing this right now

Mechanical Oil Control Gun

Super accuracy heavy duty gun for controlling fluid deliveries in most demanding applications
Oval gear mechanism
High accuracy mechanical display
Aluminium die cast meter & gun body with protective shroud on meter
Built-in continuous flow switch can be activated for unattended dispensing
Built-in swivel at inlet for easy maneuverability
Supplied complete with rigid steel extension, and manual non drip nozzle
WETTED COMPONENTS Aluminum, Acetal, Nitrile Rubber & Steel
RECOMMENDED USE Oils Upto SAE 140, Diesel, Kerosene & Engine Coolants (RTU)
DO NOT USE WITH Water Based Media, Petrol etc.

SPECIFICATIONS

Flow Rate	1-30 LPM
Accuracy	1%
Repeatability	0.30%
Max. Working Pressure	1000 PSI (70 BAR)
Pressure Loss	10 PSI (0.7 BAR)
Working Temperature Range	10C to 55C
Max. Resettable Batch Totalizer	999.9 litres
Max. Non Resettable Batch Totalizer	999999.9 litres
Least Count /Resolution	0.10 litres
Inlet Threaded	1/2″ BSPT (F)
Water Resistance	IP55

ORDERING INFORMATION
